Printer

Printing Method: Thermal Paper Width: 80mm Dots: 576 dots Effective Print Width: 72mm Print Life: 150km Print Speed: Max. 250mm/s

Cutter

Paper Thickness supported: 0.048 ~ 0.08mm Cutter Life : >1.5 Million times

Printing Paper

Paper Type: Thermal paper Paper Width :80mm Paper Thickness: 0.008 ~ 0.075mm Paper Roll Outer Diameter: 80mm Till Roll Loading Method: Top cover for easy loading

Storage

Memory: 64MB Flash: 256MB

Character Set

Font Library: Unicode character set Chinese: GB18030 24×24dots Numbering: ASCⅡ 12×24dots User Defined Character Set: Supported

Sensor

Out of Paper Sensor: Optical detection Open Cover Sensor: Mechanical detection Paper Jam Sensor: Optical detection Paper Pick-Up Sensor: Optical detection Black Mark Sensor: Optical detection Temperature Sensor: Heat detection

Indicator Lights

Power Indicator: Green Network Indicator: Blue User Reminder Indicator: White Error indicator: Red

Buttons

Volume: 2* volume +/- Function: 2* function buttons Pairing: 1* Pairing

Ethernet

Port: RJ45 Speed: 10/100Mbps

Wi-Fi

Protocol Supported: IEEE 802.11 b/g/n Frequency Band: 2.4GHz

Bluetooth

Protocol Supported: BLE, SPP, IBEACON Frequency Band: 2.4GHz

Speaker

Power: 3W Volume: ≥105dB

Power Input

Working Voltage: DC 24V/2.5A Port: DIN 4P

Ports

Cash Drawer: RJ12 24V/1A USB: TypeC USB 2.0

Environment

Operating Environment: 0°C〜50°C, 30%〜85%RH Storage Environment: -20°C〜60°C, <93%RH (40°C)

Protection Level

IP52; insect-/water-proof, easy to clean (oil)

Dimensions

130mm(L)×130mm(W)×130mm(H)

Weight

855g (without paper)

Software Supported

Print Protocol: ESC/POS Instruction set Cloud Communication: MQTT + HTTPS

Color

Black/Silver
